| Toplam Yükseklik Overall Height (mm) |
Genişlik Dimension Width (mm) |
Bağlantı Mesafesi Pipe Centres (mm) |
Duvar ile Bağlantı Mesafesi Wall to Pipe Centres (mm) |
Duvar Mesafesi Wall Distance (mm) |
| 800 | 300 | 255 | 75 – 90 | 90 – 105 |
| 1200 | 300 | 255 | 75 – 90 | 90 – 105 |
| 1600 | 300 | 255 | 75 – 90 | 90 – 105 |
| 800 | 400 | 355 | 75 – 90 | 90 – 105 |
| 1000 | 400 | 355 | 75 – 90 | 90 – 105 |
| 1200 | 400 | 355 | 75 – 90 | 90 – 105 |
| 1400 | 400 | 355 | 75 – 90 | 90 – 105 |
| 1600 | 400 | 355 | 75 – 90 | 90 – 105 |
| 1800 | 400 | 355 | 75 – 90 | 90 – 105 |
| 800 | 450 | 405 | 75 – 90 | 90 – 105 |
| 1200 | 450 | 405 | 75 – 90 | 90 – 105 |
| 1800 | 450 | 405 | 75 – 90 | 90 – 105 |
| 800 | 500 | 455 | 75 – 90 | 90 – 105 |
| 1000 | 500 | 455 | 75 – 90 | 90 – 105 |
| 1200 | 500 | 455 | 75 – 90 | 90 – 105 |
| 1400 | 500 | 455 | 75 – 90 | 90 – 105 |
| 1600 | 500 | 455 | 75 – 90 | 90 – 105 |
| 1800 | 500 | 455 | 75 – 90 | 90 – 105 |
| 800 | 600 | 555 | 75 – 90 | 90 – 105 |
| 1000 | 600 | 555 | 75 – 90 | 90 – 105 |
| 1200 | 600 | 555 | 75 – 90 | 90 – 105 |
| 1400 | 600 | 555 | 75 – 90 | 90 – 105 |
| 1600 | 600 | 555 | 75 – 90 | 90 – 105 |
| 1800 | 600 | 555 | 75 – 90 | 90 – 105 |
| 800 | 700 | 655 | 75 – 90 | 90 – 105 |
| 1000 | 700 | 655 | 75 – 90 | 90 – 105 |
| 1200 | 700 | 655 | 75 – 90 | 90 – 105 |
| 1600 | 700 | 655 | 75 – 90 | 90 – 105 |
| Toplam Yükseklik Overall Height (mm) | Genişlik Dimension Width (mm) | Bağlantı Mesafesi Pipe Centres (mm) | Duvar ile Bağlantı Mesafesi Wall to Pipe Centres (mm) | Duvar Mesafesi Wall Distance (mm) | Isı Verimi DELTA: T60C | |
| BTU | WATT | |||||
| 800 | 500 | 455 | 75 – 90 | 90 – 105 | 1341 | 393 |
| 1000 | 500 | 455 | 75 – 90 | 90 – 105 | 1641 | 481 |
| 1200 | 500 | 455 | 75 – 90 | 90 – 105 | 2008 | 588 |
| 800 | 600 | 555 | 75 – 90 | 90 – 105 | 1565 | 459 |
| 1000 | 600 | 555 | 75 – 90 | 90 – 105 | 1913 | 561 |
| 1200 | 600 | 555 | 75 – 90 | 90 – 105 | 2344 | 687 |
